Equipment · Rent or Buy
Drill Collars Rental & Sales
Slick & spiral collars for weight-on-bit
In short
Slick and spiral drill collars in a full range of OD/ID combinations to deliver weight-on-bit and keep the bottomhole assembly in compression.
Drill Collars for rent or for sale — drill collars rental, suppliers, sizes, grades and connections, delivered worldwide.
Drill collars are thick-walled steel bars that supply the weight-on-bit needed to drill ahead while keeping the neutral point above the BHA. We rent slick and spiral collars from 3⅛" to 11" OD, in API and premium connections, non-magnetic (monel) options for survey work, and with recessed slip and elevator areas for safe handling.
Popular drill collars on rental
6½" Spiral Drill Collar
6.500" OD spiral drill collar with 2¹³⁄₁₆" ID and NC50 connections for weight-on-bit.
| OD | 6.500 in |
|---|---|
| ID | 2.8125 in |
| Connection | NC50 |
| Body | Spiral |
8" Slick Drill Collar
8.000" OD slick drill collar with 2¹³⁄₁₆" ID and 6⅝" Reg connections for large-hole drilling.
| OD | 8.000 in |
|---|---|
| ID | 2.8125 in |
| Connection | 6⅝" Regular |
| Body | Slick |
6½" Non-Magnetic Drill Collar
6½" monel non-magnetic drill collar for MWD/survey isolation in directional strings.
| OD | 6.500 in |
|---|---|
| Material | Non-magnetic (monel) |
| Connection | NC50 |
Applications
- Drilling — Rotary & directional drilling strings
- Directional Drilling — Directional & horizontal BHAs
